コムクラフト | 製品案内 | ハイパワーRF/マイクロ波/コネクタ製品 | SPINNER

品番	製品概要	製品ﾀｲﾌﾟ	周波数	入力ｺﾈｸﾀおよび形状	出力ｺﾈｸﾀおよび形状
194284	Surge Protector for Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	0.0 - 2.5 GHz	7-16 male	7-16 female bulkhead
756468	Surge Protector 7-16 with in-line Quarter Wavelength Line	ハイブリッド	698 - 2700 MHz	7-16 male	7-16 female
756473	Surge Protector 7-16 with in-line Quarter Wavelength Stub, Low PIM	1/4波長スタブ	800 - 2170 MHz	7-16 male	7-16 female
756478	Surge Protector with Quarter Wavelength Stub, Low PIM	1/4波長・DCﾌﾞﾚｰｸ	698 - 2700 MHz	7-16 female bulkhead	7-16 female bulkhead
756495	Surge Protector 7-16 with in-line Quarter Wavelength Line, Low PIM	ハイブリッド	698 - 2700 MHz	7-16 male bulkhead	7-16 female bulkhead
766407	Surge Protector 7-16 with Quarter Wavelength Stub, Low PIM	1/4波長・DCﾌﾞﾚｰｸ	698 - 2700 MHz	7-16 male bulkhead	7-16 female
766410	Surge Protector with Quarter Wavelength Line	1/4波長スタブ	800 - 2500 MHz	7-16 male	7-16 female
766413	Surge Protector with Quarter Wavelength Stub, Low PIM	1/4波長・DCﾌﾞﾚｰｸ	698 - 2700 MHz	7-16 male	7-16 female bulkhead
766419	Surge Protector with Quarter Wavelength Stub	1/4波長スタブ	380 - 512 MHz	7-16 male	7-16 female
766474	Surge Protector 7-16 with Quarter Wavelength Line and Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	698 - 2700 MHz	7-16 female	7-16 female
766475	Surge Protector 7-16 with Quarter Wavelength line and Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	678 - 2700 MHz	7-16 male	7-16 female
920480	Surge Protector for Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	0.0 - 2.5 GHz	7-16 female	7-16 female bulkhead
950880	Surge Protector for Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	0.0 - 2.5 GHz	N male	N female bulkhead
950888	Surge Protector for Gas Discharge Arrestor	ｶﾞｽ放電ｱﾚｽﾀ	0.0 - 2.5 GHz	N female	N female bulkhead
A71307	Gas Discharge Arrestor, 90 V	ｶﾞｽ放電ｱﾚｽﾀ	-	-	-
A71308	Gas Discharge Arrestor, 230 V	ｶﾞｽ放電ｱﾚｽﾀ	-	-	-
A71311	Gas Discharge Arrestor, 600 V	ｶﾞｽ放電ｱﾚｽﾀ	-	-	-
A71313	Gas Discharge Arrestor, 1000 V	ｶﾞｽ放電ｱﾚｽﾀ	-	-	-
