■X線管球
X-Ray Tubes
- 多くの業界のアプリケーションニーズに基づいて開発された、幅広いメタルセラミックX線管球をご用意しております。
- ユニポーラ：75〜225kV / 1000〜4500W
- バイポーラ：320〜600kV/700〜4500W
- インサート：100〜300kV/500〜1000W
■X線管球ラインナップ
|
| P/N |
電圧
（kV） |
Focal Spot, EN
（mm） |
Max Power
（W） |
Beam Type |
仕様書 |
| MXRP 160C |
160 |
0.4 - 4.0 |
1000 |
Panoramic |
 |
| MXR 75 HP 20 FB |
75 |
1.0 |
1000 |
Fan Beam |
|
| MXR 75 HP 20 |
75 |
1.0 |
1000 |
Directional |
|
| MXR 75 30 |
75 |
5.5 |
1000 |
Directional |
|
| MXR 601 HP 11 |
600 |
0.7 - 2.0 |
700 - 1500 |
Directional |
|
| MXR 500 HP 11 |
500 |
0.4 - 1.0 |
700 - 1500 |
Directional |
|
| MXR 452 Y |
450 |
2.5 - 5.5 |
900 - 4500 |
Fan Beam |
|
| MXR 451 HP 11 |
450 |
0.4 - 1.0 |
700 - 1500 |
Directional |
|
| MXR 451 26 |
450 |
2.5 - 5.5 |
900 - 4500 |
Directional |
|
| MXR 450 XP 15 20 20 |
450 |
2.0 |
1800 |
Directional |
|
| MXR 421 HP 11 |
450 |
0.4 - 1.0 |
700 - 1500 |
Directional |
|
| MXR 421 26 |
420 |
2.5 - 5.5 |
900 - 4500 |
Directional |
|
| MXR 320 HP 11 FB 90 |
320 |
0.4 - 1.0 |
800 -1800 |
Fan Beam |
|
| MXR 320 HP 11 FB |
320 |
0.4 - 1.0 |
800 - 1800 |
Fan Beam |
|
| MXR 320 HP 11 AX |
320 |
0.4 - 1.0 |
800 - 1800 |
Directional |
|
| MXR 320 HP 11 90 |
320 |
0.4 - 1.0 |
800 - 1800 |
Directional |
|
| MXR 320 HP 11 |
320 |
0.4 - 1.0 |
800 - 1800 |
Directional |
|
| MXR 320 26 AX |
320 |
3.0 - 5.5 |
1500 - 4200 |
Directional |
|
| MXR 320 26 90 |
320 |
3.0 - 5.5 |
1500 - 4200 |
Directional |
|
| MXR 320 26 |
320 |
3.0 - 5.5 |
1500 - 4200 |
Directional |
|
| MXR 320 23 AX |
320 |
1.9 - 3.6 |
640 - 1600 |
Directional |
|
| MXR 320 23 90 |
320 |
1.9 - 3.6 |
640 - 1600 |
Directional |
|
| MXR 320 23 |
320 |
1.9 - 3.6 |
640 - 1600 |
Directional |
|
| MXR 226 |
225 |
7.5 |
3000 |
Directional |
|
| MXR 225 XP 15 15 15 |
225 |
1.5 |
2250 |
Directional |
|
| MXR 225 MF |
225 |
0.05 - 0.2 |
50 - 200 |
Directional |
|
| MXR 225 HP 11 FB |
225 |
0.4 - 1.0 |
800 - 1800 |
Fan Beam |
|
| MXR 225 HP 11 |
225 |
0.4 - 1.0 |
800 - 1800 |
Directional |
|
| MXR 225 26 |
225 |
1.2 - 5.5 |
600 - 4500 |
Directional |
|
| MXR 225 22 |
225 |
1.0 - 5.5 |
640 - 3000 |
Directional |
|
| MXR 225 21 |
225 |
1.0 - 3.0 |
640 - 1600 |
Directional |
|
| MXR 225 02 FB |
225 |
5.5 |
3000 |
Fan Beam |
|
| MXR 225 01 |
225 |
0.5 |
320 |
Directional |
|
| MXR 165 |
160 |
5.5 |
6000 |
Directional |
|
| MXR 161 FB |
160 |
5.5 |
4000 |
Fan Beam |
|
| MXR 161 |
160 |
7.5 |
3000 |
Directional |
|
| MXR 160 HP FB |
160 |
1.0 |
1000 |
Fan Beam |
|
| MXR 160 HP 20 |
160 |
1.0 |
1000 |
Directional |
|
| MXR 160 HP 11 FB |
160 |
0.4 - 1.0 |
500 - 1800 |
Fan Beam |
|
| MXR 160 HP 11 |
160 |
0.4 - 1.0 |
800 - 1800 |
Directional |
|
| MXR 160 22 |
160 |
1.0 - 5.5 |
640 - 3000 |
Directional |
|
| MXR 160 21 |
160 |
1.0 - 3.0 |
640 - 1600 |
Directional |
|
| MXR 160 20 |
160 |
1.0 |
640 |
Directional |
|
| MXR 160 01 |
160 |
0.5 |
320 |
Directional |
|
| MXR 101 |
100 |
5.5 |
1000 |
Directional |
|
| MXR 100 HP 20 FB |
90 |
1.0 |
1000 |
Fan Beam |
|
| MXR 100 HP 20 |
90 |
1.0 |
1000 |
Directional |
|
| MXR 100 30 |
90 |
5.5 |
1000 |
Directional |
|
| MXR 100 12 |
100 |
5.5 |
3000 |
Directional |
|
| MXC 453HP 11 |
450 |
0.4 - 1.2 |
700 - 1200 |
Directional |
|
| MXC 451 |
450 |
7.5 |
800 |
Directional |
|
| MXC 450 MF |
450 |
0.06 - 0.45 |
50 - 450 |
Directional |
|
| CXR 150 |
150 |
2.0 |
1000 |
Directional |
|
| CXR 105 |
100 |
3.0 |
1000 |
Directional |
|
| CXR 102 |
100 |
2.0 |
600 |
Directional |
|
|
